Resin SZUV-C6006-transparent
Introduction of 3D Printing Materials
Characteristics
SZUV-C6006
PRODUCT DESCRIPTION?
SZUV-C6006?is a clear SL resin which has accurate and durable features. It is designed for solid state SLA printers.
SZUV-C6006?can be applied in master patterns, concept models, general parts and functional prototypes in the?field of automotive, medical and consumer electronics industries.
TYPICAL FEATURES
-Medium viscosity, so easy for recoating, easy to clean parts and machines?
-Improved strength retention, improved dimensions retention of parts in humid condition?
-Good strength, need minimal part finishing?
TYPICAL BENEFITS
-Superior clear, building parts with outstanding clarity and excellent accuracy?
-Need less part finishing time, easier post-curing?
Physical Properties (Liquid)?
Appearance | Clear |
Density | 1.12g/cm3?@ 25 ℃ |
Viscosity | 408cps @ 26 ℃ |
Dp | 0.18?mm |
Ec | 6.7?mJ/cm2 |
Building layer thickness | 0.1mm |
?Mechanical Properties (Post-Cured)
MEASUREMENT | TEST METHOD | VALUE |
? | ? | 90-minute UV post-cure |
Hardness, Shore D | ASTM D 2240 | 83 |
Flexural modulus, Mpa | ASTM D 790 | 2,680-2,790 |
Flexural strength, Mpa | ASTM D 790 | 75- 83 |
Tensile modulus, MPa | ASTM D 638 | 2,580-2,670 |
Tensile strength, MPa | ASTM D?638 | 45-60 |
Elongation at break | ASTM D 638 | 11-20% |
Impact strength, notched lzod, J/m? | ASTM D 256? | 38?- 48? |
Heat deflection temperature, ℃? | ASTM D 648 @66PSI? | 52? |
Glass transition, Tg? |
DMA, E' peak |
62 |
?
?
?
Available in single scan speed, mm/s | Suggested single scanning speed, mm/s | ||
resin temperature | 18-25℃ | 23℃ | without heating |
environment humidity | 38%below | 36%below | |
laser power | 300mw | 300mw | |
support scanning speed | ≤1500 | 1200 | |
scanning interval | ≤0.1mm | 0.08mm | |
Contour scanning speed |
≤7000 | 2000 | |
Fill scanning speed | ≥4000 | 7500 |
?
